Machine tools and equipment / Metalworking machine tools / CNC machining centers / 5-Axis CNC Machining Center / 5-Axis CNC Machining Center VDU650
DMTG

5-Axis CNC Machining Center VDU650

Серия: VDU
Working table size 650mm
Max. weight of workpiece 600kg
Feed travels 650mm / 650mm / 500mm

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 650mm
T-slots 5pcs / 18mm / 45mm
Max. weight of workpiece 600kg

Feeds

Feed travels 650mm / 650mm / 500mm
A-axis Tilting Angle -130° ~ 130°
Rotation range of C-axis 360°
Max. speed of traverse feeds 30000mm/min / 30000mm/min / 30000mm/min
Max. rotation speed of axis A 5rpm
Max. rotation speed of axis C 30rpm
Rapid traverse
45000mm/min / 45000mm/min / 45000mm/min
60000mm/min / 60000mm/min / 60000mm/min

Spindle

Spindle drive Direct drive
Distance from vertical spindle nose to surface of working table 150mm / 650mm
Spindle motor power 8kW
Spindle speeds range
12000rpm
15000rpm

Accuracy

Positioning accuracy 0.008mm / 0.008mm / 0.008mm / 10'' / 10' / 8'' / 8'
Repeatability accuracy 0.005mm / 0.005mm / 0.005mm / 4'' / 3''

Automatic tool changer (ATC)

Tool magazine type Chain-type tool magazine
Taper size HSK-A63
Max. tool diameter 125mm / 76mm
Max. tool lenght 300mm
Max. tool weight 8kg
Tool magazine capacity
20pcs
30pcs
40pcs
50pcs
60pcs

CNC

CNC model Siemens ONE

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 15000kg
Overall length 5300mm
Overall width 2600mm
Overall height 3235mm
