Machine tools and equipment / Bending and forming machinery / Wire forming machinery / Spring coiling machines / 7 axis spring coiling machine JTC 720
JOINT

7 axis spring coiling machine JTC 720

Серия: JTC7
Quantity of controlled axis 7pcs
Wire diameter 0.5mm — 2mm
Wire feed value 0.01mm — 10000mm
Wire feeding speed 100m/min

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Quantity of controlled axis 7pcs
Type of spring Compression / Torsion

CNC

Spring coiling machine computer Windows based
CNC language Chinese / English
Interactive programming
No
Yes

Processing parameters

Wire diameter 0.5mm — 2mm
Wire feed value 0.01mm — 10000mm
Wire feeding speed 100m/min
Direction of coiling Right + Left
Wire feeding wheel pressing mode Mechanical

Wire feeder

Loading weight 200kg

Controlled axes

Outer diameter control mode Two curves (CAM modes)
OD control axis 1.2kW
Arbor moving axis 0.4kW / 1.2kW
Pitch axis 1pcs x 0.75kW
Wire feed axis 1pcs x 2.7kW
Cutting axis 0.75kW / 0.75kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC
Total motor power 7.75kW

Overall dimensions and weight

Weight 800kg
Overall length 1350mm
Overall width 800mm
Overall height 1800mm

Периферия

Wire feeders

JTC-200
JTC-200

Spring length detector

CXYX-1
CXYX-1

Комплектация

Diamond needle files
Количество: 1 set
Grease gun
Количество: 1 pcs
Left-direction coiling knife rest
Manual lubrication of guides
Oil gun
Количество: 1 pcs
Pneumocylinder
Количество: 1 pcs
Probe
Количество: 2 pcs
Right-direction coiling knife rest
Safety guard
Tools box
Количество: 1 pcs
Torsion spring making unit
Инструмент и оснастка для навивки
Количество: 1 set
0.5mm / 0.6mm / 0.7mm / 0.8mm / 1.0 mm / 1.2 mm / 1.4mm / 1.6mm / 1.8mm / 2.0mm
Лампа освещения рабочей зоны
Количество: 1 pcs
