WMT

Bench combination engine lathe MP-800

Max. swing diameter over bed 420mm

Range of metric threads 0.2mm — 6mm

Цена и условия

408 033 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Modification Combo lathe mill

Capability

Max. swing diameter over bed 420mm

Distance between centers 800mm

Headstock

Spindle speeds range 160rpm — 1360rpm

Spindle speed steps ranges 7pcs

Spindle taper MT4

Spindle bore diameter 28mm

Spindle motor power 0.75kW

Threading range

Range of metric threads 0.2mm — 6mm

Range of inch threads 4T.P.I. — 120T.P.I.

Tailstock

Max. travel of tailstock quill 70mm

Taper MT3

Milling head

Spindle speeds range 120rpm — 3000rpm

Spindle speed steps ranges 16pcs

Spindle taper MT3

Milling head swivel angle 360°

Face milling dimension 80mm

End milling dimension 28mm

Max. drilling diameter 22mm

Vertical stroke of spindle carrier 110mm

Overall dimensions and weight

Weight 280kg

Overall length 1430mm

Overall width 580mm

Overall height 1100mm
