Sodick

CNC Die-sink EDM machine AL40G

Серия: AL

Working table size 600mm x 400mm

X/Y-Axis travel 400mm / 300mm

Max. weight of workpiece 550kg

Цена и условия

Цена по запросу

Характеристики

Machine unit

Working table size 600mm x 400mm

Work tank inner size 750mm x 620mm x 350mm

X/Y-Axis travel 400mm / 300mm

Z-Axis travel 270mm

Max. weight of workpiece 550kg

Distance between table surface and electrode plate 150mm – 420mm

Max. electrode weight 50kg

Dielectric fluid unit

Tank capacity 285L

Pulse generator

Operating current 40A

Total power input 10kVA

CNC

EDM system CNC

Control Method CNC Close Loop

Controlled axis X-axis / Y-axis / Z-axis

Display 19″ / TFT LCD

Engines and power supply

Voltage 220V / 50Hz / Three phase / AC

Other

X-axis drive Linear motor

Y-axis drive Linear motor

Z-axis drive Linear motor

Overall dimensions and weight

Weight 4000kg

Overall length 1550mm

Overall width 2440mm

Overall height 2330mm
