DMTG

CNC Horizontal Lathe CT-40H

Серия: CT

Max. swing diameter over bed 538mm

Цена и условия

6 156 070 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 45°

C axis Presence

Capability

Max. swing diameter over bed 538mm

Processing length 450mm

Feeds

X-Axis travel 165mm

X-axis transmission type Ball screw

Z-Axis travel 500mm

Z-axis transmission type Ball screw

Max. speed of traverse feeds 9000mm/min / 9000mm/min

Rapid traverse 20000mm/min / 24000mm/min

Positioning accuracy 0.008mm / 0.008mm / 44'' / 44'

Repeatability accuracy 0.004mm / 0.004mm / 18''

Carriage

Tool post Lathe turret

Tool сhanging time (Adjacent/Farthest) 0.36sec. / 0.99sec.

Tools

Tooling Live tooling

Tools quantity 12pcs

Tool holder interface BMT45

Tool shank 25mm x 25mm

Tool shank diameter 32mm

Motor power 3.5kW

Live tooling speed 4000rpm

Tailstock

Max. travel of tailstock quill 460mm

Tailstock quill diameter 80mm

Morse cone MT4

Cutting fluid

Tank capacity 200L

Power of coolant pump motor 0.37kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Lubrication system

Lubrication system Full-automatic

Lubricatingoil pump power 0.003kW

Hydraulic system

Motor power of hydraulic station 1.5kW

Hydraulic Tank Capacity 40L

Overall dimensions and weight

Weight 4000kg

Overall length 3950mm

Overall width 1735mm

Overall height 1815mm
