STS

CNC Horizontal Lathe HCT72

Серия: HCT

Max. swing diameter over bed 500mm

Spindle speeds range 3000rpm

Spindle motor power 15kW

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Capability

Max. swing diameter over bed 500mm

Max Cutting Diameter 400mm

Headstock

Spindle speeds range 3000rpm

Lathe Spindle Nose A2-8

Spindle bore diameter 85mm

Bar Size 71mm

Spindle motor power 15kW

Model

SYNTEC 22TA

Siemens 828D

FANUC 0i-TF PLUS

Lathe chuck

Chuck size 10″

Clamping type Hydraulic

Feeds

X-Axis travel 220mm

Z-Axis travel 500mm

Rapid traverse 20000mm/min / 20000mm/min

Carriage

Tool post Lathe turret

Number of stations 12pcs

Cutting fluid

Pump motor power 0.55kW

Other

Water tank capacity 110L

Hydraulic Tank Capacity 40L

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 4500kg

Overall length 3130mm

Overall width 1777mm

Overall height 1976mm
