Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC Turning Centers / CNC Turn Mill Lathe MSY300
JSWAY

CNC Turn Mill Lathe MSY300

Серия: MSY
CNC lathe type Slant-bed CNC lathe / 30°
Processing length 300mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°
Y-axis Presence
C axis Presence

CNC

CNC
Syntec
Fanuc 0i-TF

Capability

Processing length 300mm

Main spindle

Spindle drive Direct drive
Spindle speeds range
4500rpm
4000rpm
Lathe Spindle Nose
A2-8
A2-5
A2-6
Spindle bore diameter
90mm
56mm
66mm
Bar Size
80mm
45mm
51mm
Spindle motor power
26kW
11kW
22kW

Feeds

X-Axis travel 210mm
X-axis transmission type Ball screw
Z-Axis travel 320mm
Z-axis transmission type Ball screw
Y-Axis travel 50mm
Rapid traverse 30000mm/min / 30000mm/min / 30000mm/min
Positioning accuracy 0.005mm / 0.005mm / 0.005mm
Repeatability accuracy 0.005mm / 0.005mm / 0.005mm

Feed motor

Power of feed motors 1.8kW / 1.8kW / 1.8kW

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling
Tools quantity 12pcs
Tool holder interface BMT55
Motor power 2.7kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Lubrication system

Lubrication system Full-automatic

Overall dimensions and weight

Weight 4500kg
Overall length 2240mm
Overall width 1950mm
Overall height 1950mm
