Triple Tech

CNC vertical drilling center S700

Working table size 800mm x 400mm

Spindle speeds range 20000rpm

Spindle motor power 5.5kW

Tool magazine capacity 21pcs

Цена и условия

Цена по запросу

Характеристики

Working table

Working table size 800mm x 400mm

T-slots 3pcs / 14mm / 100mm

Max. weight of workpiece 250kg

Working area

Distance between spindle axis and column 470mm

Distance from horizontal spindle nose to table surface 135mm — 435mm

Spindle

Spindle speeds range 20000rpm

Spindle motor power 5.5kW

Feeds

Feed travels 700mm / 400mm / 300mm

Rapid traverse 48000mm/min / 48000mm/min / 48000mm/min

Power of feed motors 1.5kW / 1.5kW / 3kW

CNC

Model Mitsubishi M80

Automatic tool changer (ATC)

Taper size BT30

Max. tool diameter 140mm / 100mm

Max. tool lenght 200mm

Tool сhanging time (Tool-to-Tool) 2.5sec.

Tool magazine capacity 21pcs

Max. tool weight 3kg

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3500kg

Overall length 2850mm

Overall width 1900mm

Overall height 2400mm
