WDM

CNC Vertical drilling machine ZK5150

Серия: ZK

Max. drilling diameter 50mm

Working table size 850mm x 400mm

Spindle speeds range 31.5rpm — 1400rpm

Цена и условия

3 039 386 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

CNC SINUMERIK 828

Capability

Max. drilling diameter 50mm

Working table

Working table size 850mm x 400mm

T-slots 3pcs / 14mm / 100mm

Max. weight of workpiece 300kg

Working area

Distance between spindle axis and column 335mm

Distance between spindle end and surface of worktable 80mm — 700mm

Headstock

Spindle speeds range 31.5rpm — 1400rpm

Spindle taper MT5

Feeds

Feed travels 600mm / 300mm / 250mm

Max. speed of traverse feeds 1500mm/min / 1500mm/min / 1500mm/min

Rapid traverse 8000mm/min / 8000mm/min / 2000mm/min

Accuracy

Positioning accuracy 0.03mm / 0.03mm / 0.06mm

Repeatability accuracy 0.03mm / 0.03mm / 0.04mm

Engines and power supply

Spindle motor power 3kW

Power of feed motors 1.2kW / 1.2kW / 1.2kW

Total motor power 13kW

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 1900kg

Overall length 1600mm

Overall width 1400mm

Overall height 2400mm
