KAIDA

Conventional horizontal lathe GH-1440K

Max. swing diameter over bed 356mm

Max. swing over cross slide: 210mm

Max. swing in gap 508mm

Spindle speeds range 40rpm — 1800rpm

Spindle motor power 2.4kW

Цена и условия

Цена по запросу

Характеристики

Capability

Max. swing diameter over bed 356mm

Max. swing over cross slide: 210mm

Gap Presence

Max. swing in gap 508mm

Lathe bed width 260mm

Distance between centers

750mm

1000mm

Headstock

Spindle speeds range 40rpm — 1800rpm

Spindle speed steps ranges 12pcs

Spindle taper MT5

Lathe Spindle Nose D4

Spindle bore diameter 40mm

Spindle motor power 2.4kW

Lathe chuck

Chuck 3-jaw chuck / 4-jaws chuck

Clamping type Mechanical

Feeds

Range of longitudinal feeds 0.043mm/r — 0.653mm/r

Range of cross feeds 0.024mm/r — 0.359mm/r

Threading range

Number of metric threads 37pcs

Range of metric threads 0.4mm — 7mm

Number of inch threads 28pcs

Range of inch threads 4T.P.I. — 56T.P.I.

Tailstock

Max. travel of tailstock quill 120mm

Tailstock quill diameter 45mm

Taper MT3

Cutting fluid

Power of coolant pump motor 0.04kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 1250kg

Overall length 1900mm

Overall width 710mm

Overall height 1170mm
