Machine tools and equipment / Metalworking machine tools / Metal lathes / Gang type CNC lathes / Dual-spindle Lathe with Double Gang Tool Carriers DS-6Y
DAS

Dual-spindle Lathe with Double Gang Tool Carriers DS-6Y

Серия: DS-Y
Modification Single spindle Gang type CNC lathe
Max. swing diameter over bed 450mm
Max. swing over cross slide: 400mm
Processing length 250mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Modification Single spindle Gang type CNC lathe
Bed slant angle 45°

Processing parameters

Max. swing diameter over bed 450mm
Max. swing over cross slide: 400mm
Processing length 250mm
Bar Size 45mm

Main spindle

Spindle speeds range 4500rpm
Through hole 56mm
Lathe Spindle Nose A2-5
Spindle motor power 7.5kW

Lathe chuck

Lathe chuck 152.4mm / Hydraulic

Tool Carrier

Tool post type Gand type tool post x 1pcs
tool size 20mm х 20mm
Tool Size 25mm

Live tool

Cross driven tools 4pcs / ER20 / 4000rpm
End-face driven tools 4pcs / ER20 / 4000rpm
Motor power 1.8kW

Turret

Turret type
Hydraulic
Tool number
8pcs

Feeds

X-Axis travel 1020mm / Tool Carrier
Z-Axis travel 250mm / Tool Carrier
Y-Axis travel 210mm
Feed motor power 1.3kW / 1.3kW / 0.85kW
Rapid traverse 26m/min / 18m/min / 26m/min

Accuracy

Positioning accuracy 0.005mm / 0.005mm / 0.005mm
Repeatability accuracy 0.005mm / 0.005mm / 0.005mm

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 2500kg
Overall length 2000mm
Overall width 1415mm
Overall height 1640mm
