JSWAY

Dual-spindle Lathe with Double Gang Tool Carriers DF36

Modification Single spindle Gang type CNC lathe

Max. swing over cross slide: 280mm

Processing length 100mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Modification Single spindle Gang type CNC lathe

Bed slant angle 30°

Indication and control

CNC

Syntec 22TA

Fanuc 0i-TF Plus

Processing parameters

Max. swing over cross slide: 280mm

Processing length 100mm

Bar Size 35mm

Main spindle

Spindle speeds range 6000rpm

Through hole 45mm

Lathe Spindle Nose A2-4

Spindle drive Direct drive

Spindle motor power

7.9kW

5.5kW

Tool Carrier

Tool post type Gand type tool post x 1pcs

Number of installed tool blocks 10pcs

Feeds

X-Axis travel 780mm / Tool Carrier

Z-Axis travel 300mm / Tool Carrier

Feed motor power 1.1kW / 1.1kW

Rapid traverse 36m/min / 36m/min

Accuracy

Repeatability accuracy 0.005mm / 0.008mm

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 2500kg

Overall length 2000mm

Overall width 1415mm

Overall height 1640mm

Периферия

Chip conveyors

JSWAY standard chip conveyor
