Machine tools and equipment / Metalworking machine tools / Metal lathes / Horizontal CNC Lathes / Engine lathe CNC1000
Spark

Engine lathe CNC1000

Серия: CNC
Max. swing diameter over bed 1000mm
Max. swing over cross slide: 850mm
Spindle speeds range 1200rpm
Spindle bore diameter 120mm

Основная конфигурация

Distance between centers
1000mm
1500mm
2000mm
3000mm
4000mm
5000mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe

Capability

Max. swing diameter over bed 1000mm
Max. swing over cross slide: 850mm
Max. weight of workpiece 4000kg
Bed slant angle 45°
Distance between centers
1000mm
1500mm
2000mm
3000mm
4000mm
5000mm

Headstock

Spindle speeds range 1200rpm
Spindle speed steps ranges Stepless-type
Lathe Spindle Nose A2-15
Spindle bore diameter 120mm
Spindle motor power 18.5kW

Lathe chuck

Clamping type Hydraulic
Chuck 3-jaw chuck

Feeds

X-Axis travel 500mm
Rapid traverse 10000mm/min / 8000mm/min
Z-Axis travel
1050mm
1550mm
2100mm
3100mm
4100mm
5100mm

Carriage

Tool post Lathe turret / Horizontal
Number of stations 12pcs
Axis of revolution Horizontal axis
Turning diameter 50mm
Tool shank 40mm x 40mm

Tailstock

Max. travel of tailstock quill 200mm
Tailstock quill diameter 200mm
Taper MT6

Overall dimensions and weight

Overall width 1395mm
Overall height 1650mm
