MEPER

Extrusion blow molding machine VNK85-1

Max. product volume 30L

Machine drive All-electric

Moulding Single layer

Max. mold size 1000mm x 800mm

Screw diameter 85mm

Number of stations 2pcs

Clamping force 160kN

Цена и условия

4 130 940 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Max. product volume 30L

Machine drive All-electric

Moulding Single layer

Material to be used PE / PP / HDPE

Mold

Max. mold size 1000mm x 800mm

Product volume 5L x 4pcs

Extruder

Screw diameter 85mm

Extruding output 90kg/hr

Screw ratio 28L/D

Max. rotational speed 60rpm

Number of heating zones 5pcs

Heating power 16kW

Extrusion motor power 30kW

Die head

Number of heating zones 4pcs

Heating power 20.4kW

Clamping unit

Number of stations 2pcs

Clamping force 160kN

Clamping stroke 350mm — 900mm

Platen size 1000mm x 800mm

Hydraulic system

Pump motor power 25kW

Air pressure 0.8MPa

Tank capacity 200L

Engines and power supply

Voltage 220V / 60Hz / Three phase / AC

Total motor power 92.05kW

Overall dimensions and weight

Weight 11000kg

Overall length 4700mm

Overall width 2600mm

Overall height 4000mm

Комплектация

Air compressor

Количество: 1 pcs

Chiller
