Machine tools and equipment / Plastic processing machinery / Blow molding machines / Extrusion blow molding machines (EBM) / Extrusion blow molding machine TDB-10FS
TONGDA

Extrusion blow molding machine TDB-10FS

Max. product volume 10L
Max. mold size 480mm x 530mm
Screw diameter 70mm
Number of stations 1pcs
Clamping force 95kN

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Max. product volume 10L

Mold

Max. mold size 480mm x 530mm
Production capacity 600Pcs/hr

Extruder

Screw diameter 70mm
Extruding output 85kg/hr
Screw ratio 25L/D
Number of heating zones 3pcs
Heating power 13.2kW
Extrusion motor power 22kW

Die head

Number of heating zones 4pcs
Heating power 10.5kW

Clamping unit

Number of stations 1pcs
Clamping force 95kN
Clamping stroke 410mm — 800mm

Hydraulic system

Pump motor power 16.5kW
Air pressure 0.6MPa

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC
Total motor power 63.5kW

Overall dimensions and weight

Weight 5000kg
Overall length 4100mm
Overall width 12300mm
Overall height 3100mm
