Machine tools and equipment / Plastic processing machinery / Blow molding machines / Extrusion blow molding machines (EBM) / Extrusion Blow Molding Machine TVHED-8L-2
TONVA

Extrusion Blow Molding Machine TVHED-8L-2

Machine drive Servo-Hydraulic (Hybrid)
Screw diameter 85mm
Clamping force 100kN

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Max. product volume 8L
Machine drive Servo-Hydraulic (Hybrid)
Material to be used HDPE

Extruder

Screw diameter 85mm
Extruding output 90kg/hr
Number of heating zones 6pcs
Heating power 16kW
Extrusion motor power 30kW

Die head

Quantity of Die heads 2pcs
Number of heating zones 3pcs
Heating power 6kW

Clamping unit

Number of stations 2pcs
Clamping force 100kN
Clamping stroke 300mm — 600mm
Platen size 400mm x 470mm

Hydraulic system

Pump motor power 11kW
Air pressure 0.6MPa

Engines and power supply

Total motor power 63kW

Overall dimensions and weight

Weight 10000kg
Overall length 4900mm
Overall width 3400mm
Overall height 2300mm

Комплектация

Air compressor
Количество: 1 pcs
Air tank
Количество: 1 pcs
Auto-feeder
Количество: 1 pcs
Chiller
Количество: 1 pcs
Crusher
Количество: 1 pcs
EHC
Количество: 1 pcs
Hybrid system
Количество: 1 pcs
Level line
Количество: 1 pcs
Parison controller
Количество: 1 pcs
