Machine tools and equipment / Metalworking machine tools / Metal lathes / Conventional lathes / Gap bed lathe C6251
Caiman

Gap bed lathe C6251

Max. swing diameter over bed 510mm
Max. swing over cross slide: 310mm
Max. swing in gap 740mm

Цена и условия

Цена по запросу

Характеристики

Capability

Max. swing diameter over bed 510mm
Max. swing over cross slide: 310mm
Gap Presence
Max. swing in gap 740mm
Center height 255mm
Lathe bed width 350mm
Distance between centers
1500mm
2000mm
3000mm

Headstock

Spindle speeds range 25rpm — 1600rpm
Spindle taper MT7
Lathe Spindle Nose D1-8
Spindle bore diameter 80mm
Spindle motor power 7.5kW

Lathe chuck

Chuck 3-jaw chuck

Feeds

Range of longitudinal feeds 0.059mm/r — 1.646mm/r
Range of cross feeds 0.02mm/r — 0.573mm/r

Threading range

Range of metric threads 0.2mm — 14mm
Range of inch threads 2T.P.I. — 1112T.P.I.
Range of modular threads cutting 0.1module — 7module
Range of pitch threads 4D.P. — 112D.P.

Carriage

Top slide travel 135mm
Max. cross travel of lower slide 320mm

Tailstock

Max. travel of tailstock quill 180mm
Tailstock quill diameter 75mm
Taper MT5

Cutting fluid

Power of coolant pump motor 0.09kW
