Machine tools and equipment / Metalworking machine tools / Metal lathes / Horizontal CNC Lathes / Horizontal CNC Lathe CK6136S
KAIDA

Horizontal CNC Lathe CK6136S

Серия: CK-S
CNC lathe type Flat-bed CNC lathe
Max. swing diameter over bed 360mm
Max. swing over cross slide: 180mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Flat-bed CNC lathe

Capability

Max. swing diameter over bed 360mm
Standard Cutting Diameter 280mm
Max. swing over cross slide: 180mm
Distance between centers
500mm
750mm
1000mm
Processing length
450mm
700mm
950mm

Headstock

Type of electric motor Servomotor
Spindle speeds range 200rpm — 2800rpm
Spindle speed steps ranges Stepless-type
Spindle taper MT5
Lathe Spindle Nose C5
Spindle bore diameter 40mm
Spindle motor power
3.7kW
5.5kW

Lathe chuck

Chuck size 200mm
Clamping type Mechanical
Chuck 3-jaw chuck

Feeds

X-Axis travel 215mm
Rapid traverse 8000mm/min / 10000mm/min
Z-Axis travel
490mm
740mm
990mm

Carriage

Tool shank 20mm x 20mm

Tailstock

Max. travel of tailstock quill 120mm
Tailstock quill diameter 60mm
Taper MT4
Tailstock
Manual
Hydraulic

CNC

Model FANUC 0i TF (5) Plus

Overall dimensions and weight

Weight 1700kg
Overall length 2120mm
Overall width 1200mm
Overall height 1415mm

Периферия

Lathe toolposts

C6136S 4 pos toolpost
C6136S 4 pos toolpost
C6136S 6 pos toolpost
C6136S 6 pos toolpost
