KAIDA

Horizontal CNC Lathe KDCL-30L

Серия: KDCL

CNC lathe type Slant-bed CNC lathe / 45°

Max. swing diameter over bed 650mm

Max. turning dia 320mm / 500mm

Processing length 900mm

Spindle bore diameter 105mm

Цена и условия

8 454 937 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 45°

Capability

Max. swing diameter over bed 650mm

Max. turning dia 320mm / 500mm

Processing length 900mm

Headstock

Spindle drive Belt drive

Spindle speeds range 2000rpm

Lathe Spindle Nose A2-11

Spindle bore diameter 105mm

Spindle motor power 18.5kW / 22kW

Lathe chuck

Chuck size 12″

Clamping type Hydraulic

Chuck 3-jaw chuck

Through hole Presence

Feeds

X-Axis travel 270mm

X-axis transmission type Ball screw

Z-Axis travel 1060mm

Z-axis transmission type Ball screw

Rapid traverse 16000mm/min / 20000mm/min

Repeatability accuracy 0.006mm / 0.006mm

Carriage

Tool post Lathe turret

Number of stations 12pcs

Tailstock

Tailstock Hydraulic

Max. travel of tailstock quill 200mm

Tailstock quill diameter 100mm

Taper MT6

CNC

Model FANUC OI-TF (5)

Chip and dust removal systems

Chip removal system Chain type chip conveyor

Chip carrier Presence

Overall dimensions and weight

Weight 9000kg

Overall length 4250mm

Overall width 1980mm

Overall height 2260mm
