KDE

Horizontal CNC Lathe TCK56-500

CNC lathe type Slant-bed CNC lathe / 45°

Max. swing diameter over bed 560mm

Max Cutting Diameter 350mm

Max. swing over cross slide: 330mm

Processing length 500mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 45°

Capability

Max. swing diameter over bed 560mm

Max Cutting Diameter 350mm

Standard Cutting Diameter 280mm

Max. swing over cross slide: 330mm

Processing length 500mm

Headstock

Spindle drive Belt drive

Spindle speeds range 50rpm — 4000rpm

Spindle speed steps ranges Stepless-type

Lathe Spindle Nose A2-6

Spindle bore diameter 65mm

Bar Size 50mm

Spindle torque 177N⋅m

Spindle motor power 11kW / 15kW

Model

KND K2000TF3i-D

HNC-818F

Fanuc

Lathe chuck

Chuck size 8″

Clamping type Hydraulic

Feeds

X-Axis travel 200mm

X-axis transmission type Ball screw

Z-Axis travel 530mm

Z-axis transmission type Ball screw

Rapid traverse 20000mm/min / 20000mm/min

Positioning accuracy 0.008mm / 0.008mm

Repeatability accuracy 0.004mm / 0.004mm

Carriage

Tool post Lathe turret

Number of stations 8pcs

Tool Size 40mm

Tool shank 25mm x 25mm

Tailstock

Tailstock Hydraulic

Taper MT5

Other

Accuracy class index IT6

Best surface roughness 1.25μm/Ra

Overall dimensions and weight

Weight 3500kg

Overall length 2900mm

Overall width 1900mm

Overall height 1950mm

Периферия

Lathe toolposts

T 5.2 toolpost 8 pcs

T 5.2 toolpost 12 pcs
