KAIDA

Manual Lathe C6277C

Серия: C

Max. swing diameter over bed 770mm

Max. swing over cross slide: 520mm

Max. swing in gap 970mm

Spindle speeds range 36rpm — 1600rpm

Spindle motor power 7.5kW

Основная конфигурация

Distance between centers

1000mm

1500mm

2000mm

3000mm

4000mm

Характеристики

Capability

Max. swing diameter over bed 770mm

Max. swing over cross slide: 520mm

Gap Presence

Max. swing in gap 970mm

Lathe bed width 405mm

Distance between centers

1000mm

1500mm

2000mm

3000mm

4000mm

Headstock

Spindle speeds range 36rpm — 1600rpm

Spindle speed steps ranges 12pcs

Lathe Spindle Nose D8

Spindle bore diameter 105mm

Spindle motor power 7.5kW

Lathe chuck

Chuck 3-jaw chuck / 4-jaws chuck

Clamping type Mechanical

Feeds

Range of longitudinal feeds 0.063mm/r — 2.52mm/r

Range of cross feeds 0.027mm/r — 1.07mm/r

Rapid traverse 4500mm/min / 1900mm/min

Threading range

Number of metric threads 22pcs

Range of metric threads 1mm — 14mm

Number of inch threads 26pcs

Range of inch threads 2T.P.I. — 28T.P.I.

Number of module threads 18pcs

Range of modular threads cutting 0.5module — 7module

Number of pitch threads 24pcs

Range of pitch threads 56D.P. — 4D.P.

Carriage

Tailstock

Max. travel of tailstock quill 150mm

Tailstock quill diameter 75mm

Taper MT5

Engines and power supply

Voltage 380V / 50Hz

Периферия

Digital Readout Unit (DRO)

DRO SINO SDS6-2V
