KAIDA

Manual Lathe GH-1640

Max. swing diameter over bed 400mm

Max. swing over cross slide: 250mm

Max. swing in gap 660mm

Spindle speeds range 42rpm — 1800rpm

Spindle motor power 5.5kW

Основная конфигурация

Distance between centers

1000mm

1500mm

2000mm

Характеристики

Capability

Max. swing diameter over bed 400mm

Max. swing over cross slide: 250mm

Max. swing in gap 660mm

Lathe bed width 336mm

Distance between centers

1000mm

1500mm

2000mm

Headstock

Spindle speeds range 42rpm — 1800rpm

Spindle speed steps ranges 12pcs

Spindle taper MT7

Lathe Spindle Nose D1-8

Spindle bore diameter 80mm

Spindle motor power 5.5kW

Lathe chuck

Lathe chuck 250mm / Mechanical / 3-jaw chuck

Feeds

Range of longitudinal feeds 0.04mm/r — 2.46mm/r

Range of cross feeds 0.02mm/r — 1.23mm/r

Threading range

Number of metric threads 24pcs

Range of metric threads 0.5mm — 20mm

Number of inch threads 61pcs

Range of inch threads 1.625T.P.I. — 72T.P.I.

Number of module threads 20pcs

Range of modular threads cutting 0.25module — 10module

Number of pitch threads 45pcs

Range of pitch threads 96D.P. — 3.25D.P.

Carriage

Tailstock

Max. travel of tailstock quill 130mm

Taper MT5

Engines and power supply

Voltage 380V / 50Hz

Периферия

Digital Readout Unit (DRO)

DRO SINO SDS6-3V

DRO SINO SDS6-2V
