Metal lathe CK(W)61125E

Серия: CK61(W)

Max. swing diameter over bed 1250mm

Max. swing over cross slide: 900mm

Max. weight of workpiece 8000kg

Lathe bed width 755mm

Spindle speeds range 4rpm — 400rpm

Spindle speed steps ranges Stepless-type / 4pcs

Tool shank 45mm x 45mm

Основная конфигурация

Distance between centers

1500mm

2000mm

3000mm

4000mm

5000mm

6000mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Flat-bed CNC lathe

Capability

Max. swing diameter over bed 1250mm

Max. swing over cross slide: 900mm

Max. weight of workpiece 8000kg

Lathe bed width 755mm

Distance between centers

1500mm

2000mm

3000mm

4000mm

5000mm

6000mm

Processing length

1250mm

1750mm

2750mm

3750mm

4750mm

5750mm

Headstock

Spindle speeds range 4rpm — 400rpm

Spindle speed steps ranges Stepless-type / 4pcs

Spindle taper Metric #140

Lathe Spindle Nose A2-15

Spindle bore diameter 130mm

Model

Fanuc 0i-TF

Siemens 828D

Spindle motor power

9kW / 11kW

Feeds

X-Axis travel 650mm

Rapid traverse 6000mm/min / 4000mm/min

Carriage

Tool post 4-station turret toolpost

Number of stations 4pcs

Axis of revolution Vertical axis

Max. cross travel of lower slide 650mm

Tool shank 45mm x 45mm

Tailstock

Max. travel of tailstock quill 300mm

Tailstock quill diameter 160mm

Taper MT6
