Weiss

Milling and drilling machine VM25L

Серия: VM

Milling machine variation Vertical milling machine / Drilling-and-milling machine / Bench type

Max. drilling diameter 25mm

Face milling dimension 63mm

End milling dimension 16mm

Working table size 700mm x 180mm

Цена и условия

212 407 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Milling machine variation Vertical milling machine / Drilling-and-milling machine / Bench type

Capability

Max. drilling diameter 25mm

Face milling dimension 63mm

End milling dimension 16mm

Vertical worktable

Working table size 700mm x 180mm

T-slots 3pcs / 12mm

Vertical spindle

Spindle speeds range 100rpm — 2500rpm

Spindle speed steps ranges Stepless-type

Spindle taper MT3

Travel of spindle quill 50mm

Distance between spindle end and surface of worktable 320mm

Spindle motor power 1.1kW

Feeds

Manual feed travels 495mm / 150mm / 275mm

Engines and power supply

Voltage 230V / Single phase

Overall dimensions and weight

Weight 120kg

Overall length 730mm

Overall width 710mm

Overall height 880mm

Периферия

Digital Readout Unit (DRO)

D80-3V-DC10

D80-2V-DC10

Комплектация

Chip collector tray

Drilling chuck

Drilling vice

Reduction sleeve

Tools box
