Weiss

Milling and drilling machine WMD45

Серия: WMD

Milling machine variation Drilling-and-milling machine / Bench type

Max. drilling diameter 32mm / 45mm

Working table size 800mm x 240mm

T-slots 3pcs / 14mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Milling machine variation Drilling-and-milling machine / Bench type

Milling Vertical

Capability

Max. drilling diameter 32mm / 45mm

Face milling dimension 80mm

End milling dimension 32mm

Vertical worktable

Working table size 800mm x 240mm

T-slots 3pcs / 14mm

Vertical spindle

Spindle speeds range 90rpm — 1920rpm

Spindle speed steps ranges 6pcs

Spindle taper ISO30

Milling head swivel angle 45°

Travel of spindle quill 120mm

Distance from axis of vertical spindle to bed guideway 260mm

Distance between spindle end and surface of worktable 470mm

Spindle motor power 1.5kW

Feeds

Manual feed travels 560mm / 230mm

Engines and power supply

Voltage 110V / 60Hz / Single phase

Overall dimensions and weight

Weight 250kg

Overall length 1447mm

Overall width 711mm

Overall height 686mm

Комплектация

Draw bar

Mill arbors

Milling chuck

Reduction sleeve

Tools box
