Pipe threading machine Q1322 (Luzhong), China | Low price

Capability

Outer diameter of pipe 50mm — 220mm

Max. weight of workpiece 3000kg

Max. swing diameter over bed

630mm

800mm

Max. swing over cross slide:

340mm

520mm

Distance between centers

1500mm

3000mm

Headstock

Spindle speed steps ranges 4pcs

Spindle speeds range 20rpm — 550rpm

Spindle bore diameter 230mm

Spindle motor power 11kW

Feeds

Range of longitudinal feeds 22mm/r

Range of cross feeds 26mm/r

Rapid traverse 2300mm/min / 4000mm/min

Power of rapid feed motors 0.3kW

X-Axis travel

320mm

420mm

Z-Axis travel

1350mm

2850mm

Threading range

Range of inch threads 1T.P.I. — 14T.P.I.

Range of metric threads 1mm — 15mm

Lathe chuck

Chuck size 520″

Chuck 4-jaws chuck

Clamping type Mechanical

Carriage

Tool shank 32mm x 32mm

Tailstock

Max. travel of tailstock quill 250mm

Tailstock quill diameter 100mm

Taper MT5

Cutting fluid

Power of coolant pump motor 0.125kW

Overall dimensions and weight

Weight 4500kg

Overall length 3700mm

Overall width 1650mm

Overall height 1550mm
