Basic feauturies
Linear axis number
6pcs / X1 / X2 / Y1 / Y2 / Z1 / Z2
Total tools quantity
10pcs / 13pcs / 23pcs
Modification
Dual spindles swiss-type lathe
Processing parameters
Machining range diameter (spindle/subspindle)
32mm / 32mm
Max. processing length
190mm / Replaceable fixed guide bushing
Main spindle
Spindle drive
Direct drive
Spindle cooling
Oil cooling
Spindle speeds range
8000rpm
Spindle bore diameter
34mm
C axis
Presence / 0.001°
Max. drilling diameter
13mm
Tapping capacity
M12
Motor power
3.7kW / 7.5kW
Back spindle
Spindle drive
Direct drive
Spindle cooling
Oil cooling
Spindle speeds range
8000rpm
Spindle bore diameter
34mm
C axis
Presence / 0.001°
Max. drilling diameter
10mm
Tapping capacity
M8
Motor power
3.7kW / 7.5kW
Cross driven tools main spindle
Cross driven tools
5pcs / ER16 / 5000rpm
Max. drilling diameter
10mm
Tapping capacity
М8
Motor power
1.7kW
Main spindle O.D. turning tools
Tool seat arrangement
Upside tool holder
Tool number
6pcs
Tool Size
16mm x 16mm
Main spindle end face tools
End-face fixed tools
3pcs / ER16
End-face fixed tools
1pcs / ER20
Sub-spindle end face tools
End-face driven tools
8pcs / ER16
Linear axes
Rapid traverse
24m/min / 24m/min / 24m/min / 24m/min / 24m/min / 24m/min
Axis drive motor power
1.1kW
Other
Water tank capacity
286L
Overall dimensions and weight
Weight
3980kg
Overall length
2470mm
Overall width
1600mm
Overall height
2000mm
