STS

Turning center TXY46

Серия: TXY

Max. swing diameter over bed 400mm

Spindle speeds range 4000rpm

Spindle motor power 7.5kW

Цена и условия

7 450 488 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Y-axis Presence

Capability

Max. swing diameter over bed 400mm

Main spindle

Spindle speeds range 4000rpm

Lathe Spindle Nose A2-5

Spindle bore diameter 56mm

Bar Size 45mm

Spindle motor power 7.5kW

Feeds

X-Axis travel 200mm

Z-Axis travel 350mm

Y-Axis travel 45mm

Rapid traverse 20000mm/min / 20000mm/min

Positioning accuracy 0.01mm / 0.01mm / 0.01mm

Repeatability accuracy 0.005mm / 0.005mm / 0.005mm

Tools

Tooling Live tooling

Tools quantity 15pcs

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3800kg

Overall length 2240mm

Overall width 1960mm

Overall height 2180mm
