SGSK

Vertical CNC Lathe VTC850

Серия: VTC

Max. swing diameter over bed 850mm

Turning diameter 750mm

Spindle speeds range 30rpm — 800rpm

Number of stations 8pcs

Цена и условия

10 281 623 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Capability

Max. swing diameter over bed 850mm

Turning diameter 750mm

Spindle

Spindle speeds range 30rpm — 800rpm

Lathe Spindle Nose A2-11

Spindle Bearing Inner Diameter 180mm

Spindle torque 890N⋅m

Lathe chuck

Clamping type Hydraulic

Chuck size 24″

Feeds

X-Axis travel -500mm

Z-Axis travel 800mm

Max. speed of traverse feeds 5000mm/min / 5000mm/min

Rapid traverse 15000mm/min / 12000mm/min

X-axis transmission type Ball screw / Ø 50mm

Z-axis transmission type Ball screw / Ø 40mm

Power of feed motors 2.8kW / 3.5kW

Carriage

Tool post Lathe turret / Horizontal

Number of stations 8pcs

Tool shank 32mm x 32mm

CNC

CNC model Fanuc 0i TF (5)

Chip and dust removal systems

Chip removal system Chain type chip conveyor

Overall dimensions and weight

Weight 9500kg

Overall length 2500mm

Overall width 2250mm

Overall height 3150mm
