SGSK

Vertical CNC machining center VMC640

Working table size 800mm x 300mm

Max. weight of workpiece 300kg

Spindle speeds range 8000rpm

Feed travels 600mm / 360mm / 450mm

Цена и условия

3 702 633 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Working table

Working table size 800mm x 300mm

T-slots 3pcs / 16mm / 80mm

Max. weight of workpiece 300kg

Spindle

Spindle speeds range 8000rpm

Spindle taper BT40

Spindle motor power 5.5kW

Distance from axis of vertical spindle to bed guideway 410mm

Distance from vertical spindle nose to surface of working table 100mm / 550mm

Accuracy

Positioning accuracy 0.0075mm / 0.0075mm / 0.0075mm

Repeatability accuracy 0.005mm / 0.005mm / 0.005mm

Automatic tool changer (ATC)

Tool magazine capacity 16pcs

Max. tool diameter 90mm

Max. tool weight 8kg

Feeds

Feed travels 600mm / 360mm / 450mm

Rapid traverse 24000mm/min / 24000mm/min / 20000mm/min

CNC

Model Fanuc

Engines and power supply

Voltage 380V / 50Hz

Overall dimensions and weight

Weight 3000kg

Overall length 1900mm

Overall width 1700mm

Overall height 2100mm
