WDM

Vertical drilling machine Z4116

Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine

Design drilling machine

Max. drilling diameter 16mm

Distance between spindle end and surface of worktable 297mm

Spindle speeds range 365rpm — 3150rpm

Travel of spindle quill 125mm

Spindle motor power 0.75kW

Цена и условия

136 123 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine

Design drilling machine

Capability

Max. drilling diameter 16mm

Working table

Working table size 280mm x 300mm

Working area

Diameter of column 85mm

Distance between spindle axis and column 240mm

Distance between spindle end and working surface of basic plate 560mm

Distance between spindle end and surface of worktable 297mm

Headstock

Spindle speed steps ranges 5pcs

Spindle speeds range 365rpm — 3150rpm

Spindle feeds 5pcs

Travel of spindle quill 125mm

Lathe Spindle Nose MT2

Base

Base size 590mm x 375mm

Engines and power supply

Spindle motor power 0.75kW

Voltage 380V / 50Hz

Overall dimensions and weight

Weight 102kg

Overall length 495mm

Overall width 375mm

Overall height 850mm

Комплектация

Drift

Drilling chuck

Drilling vice

Reduction sleeve

MT3

Safety guard

Wrench
