WDM

Vertical drilling machine Z5050V

Vertical drilling machine variation Round column vertical drilling machine

Design drilling machine

Max. drilling diameter 50mm

Tapping capacity M30

Spindle speeds range 50rpm — 2000rpm

Travel of spindle quill 240mm

Цена и условия

1 049 923 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine

CNC Absence

Design drilling machine

Capability

Max. drilling diameter 50mm

Tapping capacity M30

Working table

Working table size 550mm x 470mm

Working area

Diameter of column 180mm

Distance between spindle axis and column 360mm

Distance between spindle end and working surface of basic plate 1160mm

Distance between spindle end and surface of worktable 570mm

Headstock

Spindle speeds range 50rpm — 2000rpm

Spindle taper MT4 / MT5

Travel of spindle quill 240mm

Base

Base size 450mm x 440mm

Engines and power supply

Spindle motor power 2.2kW / 2.8kW

Overall dimensions and weight

Weight 985kg

Overall length 1800mm

Overall width 620mm

Overall height 2450mm
