WDM

Vertical drilling machine ZW4116

Серия: ZW

Vertical drilling machine variation Round column vertical drilling machine

Max. drilling diameter 16mm

Distance between spindle end and surface of worktable 590mm

Spindle speeds range 300rpm — 3000rpm

Цена и условия

198 681 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine

Design drilling machine

Capability

Max. drilling diameter 16mm

Tapping capacity M10

Working table

Working table size 250mm x 250mm

Working area

Diameter of column 70mm

Distance between spindle axis and column 193mm

Distance between spindle end and working surface of basic plate 805mm

Distance between spindle end and surface of worktable 590mm

Headstock

Spindle speeds range 300rpm — 3000rpm

Spindle taper MT2

Spindle torque 16N⋅m

Base

Base size 300mm x 300mm

Engines and power supply

Spindle motor power 1.5kW

Overall dimensions and weight

Weight 145kg

Overall length 640mm

Overall width 450mm

Overall height 1370mm
