Wellon

Vertical drilling machine ZX-40HC

Серия: ZX

Vertical drilling machine variation Round column vertical drilling machine

Max. drilling diameter 32mm / 40mm

Working table size 585mm x 190mm

Цена и условия

296 236 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine

CNC Absence

Design drilling machine

Capability

Max. drilling diameter 32mm / 40mm

Working table

Working table size 585mm x 190mm

Working area

Diameter of column 115mm

Distance between spindle axis and column 272.5mm

Distance between spindle end and working surface of basic plate 1245mm

Distance between spindle end and surface of worktable 745mm

Headstock

Spindle speed steps ranges 6pcs

Spindle speeds range 95rpm — 1600rpm

Spindle taper MT4

Vertical stroke of spindle carrier 120mm

Base

Base size 635mm x 460mm

Engines and power supply

Spindle motor power 11kW / 3pcs

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 310kg

Overall length 720mm

Overall width 740mm

Overall height 1860mm

Комплектация

Chuck guard

Cutter

80mm

Drilling chuck

16mm

Drilling vice

Milling chuck

Reduction sleeve
