XILI

Vertical drilling machine Z5150B

Vertical drilling machine variation Square column vertical drilling machine

Max. drilling diameter 50mm

Working table size 560mm x 480mm

Spindle speeds range 31.5rpm — 1400rpm

Цена и условия

1 185 383 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Vertical drilling machine variation Square column vertical drilling machine

CNC Absence

Design drilling machine

Capability

Max. drilling diameter 50mm

Working table

Working table size 560mm x 480mm

Working area

Distance between spindle axis and column 335mm

Distance between spindle end and surface of worktable 750mm

Headstock

Spindle speed steps ranges 12pcs

Spindle speeds range 31.5rpm — 1400rpm

Spindle feeds 9pcs

Range of spindle feeds 0.056mm/r — 1.80mm/r

Spindle taper MT5

Travel of spindle quill 250mm

Vertical stroke of spindle carrier 360mm

Feeds

Feed travels 300mm

Engines and power supply

Spindle motor power 3kW

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 1250kg

Overall length 1090mm

Overall width 905mm

Overall height 2465mm

Комплектация

Coolant cooling system

Drilling chuck

Reduction sleeve

Tools box
