Caiman

Wire cut EDM FR7055S

Working table size 810mm x 1040mm

Max. weight of workpiece 600kg

X/Y-Axis travel 550mm / 700mm

Z-Axis travel 400mm

Цена и условия

5 998 211 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Machine unit

Machining method Flushing type

Working table size 810mm x 1040mm

Max. weight of workpiece 600kg

Max. taper angle 6° / 80mm

Wire Molybdenum

Wire diameter 0.16mm — 0.2mm

Wire feeding speed 2m/min — 11m/min

CNC

Software Windows based

Controlled axis X-axis / Y-axis / Z-axis / U-axis / V-axis

Feeds

X/Y-Axis travel 550mm / 700mm

Z-Axis travel 400mm

U-Axle travel 20mm

V-Axle travel 20mm

Accuracy

Machining Accuracy 0.005mm

Best surface roughness 0.8μm/Ra

Pulse generator

Cutting speed 300mm²/min

Overall dimensions 800mm x 620mm x 1800mm

Weight 400kg

Dielectric fluid unit

Tank capacity 180L

Overall dimensions 960mm x 580mm x 530mm

Other

X-axis drive Servomotor

Y-axis drive Servomotor

Z-axis drive Servomotor

U-axis drive Servomotor

V-axis drive Servomotor

Overall dimensions and weight

Weight 2850kg

Overall length 2150mm

Overall width 1830mm

Overall height 2280mm

Комплектация

Clamping tool

Tools box

Wire

Wire guide
