WeCoil

X-type spring forming machine HCT-NM1225X

Серия: X

Quantity of controlled axis 12pcs

Spring-forming machine variation Сamless machine / X-type spring forming machine

Wire diameter 0.3mm — 2.5mm

Sliders axis 4pcs x 1kW

Toolholder lateral movment axis 4pcs x 1.2kW

Цена и условия

5 640 525 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Quantity of controlled axis 12pcs

Type of spring Compression / Tension / Torsion / Double torsion / Wire bending

Spring-forming machine variation Сamless machine / X-type spring forming machine

CNC

CNC language Chinese / English

Processing parameters

Wire diameter 0.3mm — 2.5mm

Direction of coiling Right + Left

Wire feeding speed 120m/min

Wire feeder

Loading weight 200kg

Controlled axes

Sliders axis 4pcs x 1kW

Toolholder lateral movment axis 4pcs x 1.2kW

Wire feed axis 1pcs x 2.7kW

Core axis 1pcs x 1kW

Wire rotary axis 1pcs x 2.7kW

Spinner 1pcs x 0.4kW

Engines and power supply

Total motor power 15.6kW

Voltage 380V / 50Hz / Three phase

Overall dimensions and weight

Weight 1500kg

Overall length 1600mm

Overall width 1120mm

Overall height 1750mm
