Machine tools and equipment / Metalworking machine tools / Electrical discharge machines (EDM) / Die-sink EDM machine / ZNC Die-sink EDM machine HQ-540K
Caiman

ZNC Die-sink EDM machine HQ-540K

Серия: HQ(K)
Working table size 800mm x 500mm
X/Y-Axis travel 500mm / 400mm
Ram vertical travel 300mm
Max. weight of workpiece 1800kg

Цена и условия

4 796 457 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Machine unit

Working table size 800mm x 500mm
Work tank inner size 1300mm x 920mm x 500mm
X/Y-Axis travel 500mm / 400mm
Ram vertical travel 300mm
Max. weight of workpiece 1800kg
Max. electrode weight 50kg

Dielectric fluid unit

Tank capacity 500L
Filter type Paper filter

Pulse generator

Operating current 50A
Max.material removal rate 500mm³/min
Electrode wear rate 0.1%
Best surface roughness 0.1μm/Ra

CNC

Software Linux
EDM system CNC
Controlled axis X-axis / Y-axis / Z-axis
Setting limits 0.001mm
Display 17″

Engines and power supply

Voltage 380V / 50Hz
Motor type Servomotor

Other

Y-axis drive Servomotor
X-axis drive Servomotor
Z-axis drive Servomotor

Overall dimensions and weight

Weight 3800kg
Overall length 1640mm
Overall width 2500mm
Overall height 2150mm

Комплектация

3-axes linear scale
Auto. Tool change
C axis
Chiller
Electrode holder
Количество: 1 set
EROWA clamping tool
Filter
Количество: 2 pcs
Magnetic chuck
Количество: 1 pcs
400mm х 200mm
Manual chuck
Pneumatic chuck
Tools box
Количество: 1 pcs
