Caiman

ZNC Die-sink EDM machine HQ-550(ZK)

Серия: HQ(ZK)

Working table size 800mm x 500mm

X/Y-Axis travel 550mm / 450mm

Ram vertical travel 300mm

Max. weight of workpiece 1000kg

Цена и условия

2 579 235 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Machine unit

Die-sink EDM Machine design Movable table

Design specifics Machine units are separate

Working table size 800mm x 500mm

Work tank inner size 1300mm x 770mm x 550mm

X/Y-Axis travel 550mm / 450mm

Ram vertical travel 300mm

Z-Axis travel 250mm

Max. weight of workpiece 1000kg

Distance between table surface and electrode plate 820mm

Max. electrode weight 100kg

Pulse generator

Operating current 75A

Model HQ-75C

Max.material removal rate 500mm³/min

Electrode wear rate 0.1%

Accuracy

Best surface roughness 0.8μm/Ra

CNC

EDM system ZNC

Controlled axis Z-axis

Display 15″

Engines and power supply

Voltage 380V / 50Hz

Overall dimensions and weight

Weight 2500kg

Overall length 4000mm

Overall width 2500mm

Overall height 2600mm
