Machine tools and equipment / Bending and forming machinery / Wire forming machinery / Spring forming machines / 12-axis CNC spring forming machine CNC-1255
WNJ

12-axis CNC spring forming machine CNC-1255

Серия: CNC
Quantity of controlled axis 12pcs
Spring-forming machine variation Сamless machine
Wire diameter 2mm — 5.5mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Quantity of controlled axis 12pcs
Type of spring Tension / Torsion / Double torsion / Wire bending
Spring-forming machine variation Сamless machine

CNC

CNC language Chinese / English

Processing parameters

Wire diameter 2mm — 5.5mm
Wire feeding speed 68m/min

Controlled axes

Sliders axis 8pcs x 2.7kW
Wire feed axis 1pcs x 7.5kW
Core axis 1pcs x 1.5kW
Wire rotary axis 1pcs x 2.7kW
Spinner 1.5kW

Engines and power supply

Total motor power 36kW
Voltage 380V / 50Hz / Three phase

Overall dimensions and weight

Weight 5300kg
Overall length 2400mm
Overall width 2900mm
Overall height 2150mm

Периферия

Wire feeders

SLB-150
SLB-150
Diameter of feeding tray : 800mm , Loading weight : 150kg , Wire feeding speed : 120m/min , Motor power : 0.25kW

Комплектация

Fastening bolts
Oil gun
Количество: 1 pcs
Probe
Servo cutter
Tools box
Количество: 1 pcs
Инструмент и оснастка для навивки
Количество: 1 set
Лампа освещения рабочей зоны
Количество: 1 pcs
