KAIDA

5-Axis CNC Machining Center KDU650V

Серия: KDU

Working table size 650mm

Max. weight of workpiece 300kg

Feed travels 820mm / 520mm / 500mm

B Axis Tilting Range 120°

Rotation range of C-axis 360°

Цена и условия

31 161 513 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Working table

Working table size 650mm

T-slots 5pcs / 14mm / 45mm

Max. weight of workpiece 300kg

Feeds

Feed travels 820mm / 520mm / 500mm

B Axis Tilting Range 120°

Rotation range of C-axis 360°

Max. rotation speed of the B-axis 60rpm

Max. rotation speed of axis C 100rpm

Rapid traverse 36000mm/min / 36000mm/min / 36000mm/min

Torque of axis-drive motors 27N⋅m / 27N⋅m / 27N⋅m / 600N⋅m / 2000N⋅m

Spindle

Spindle drive Direct drive

Spindle speeds range 12000rpm

Spindle taper BT40

Distance from vertical spindle nose to surface of working table 180mm / 620mm

Spindle motor power 11kW / 15kW

Accuracy

Positioning accuracy 12'' / 12'' / 12'

Repeatability accuracy 0.006mm / 0.004mm / 0.004mm / 6'' / 6''

Automatic tool changer (ATC)

Tool magazine capacity 24pcs

Tool сhanging time (Tool-to-Tool) 2sec.

CNC

CNC model Siemens 840D SL

Cutting fluid

Water tank capacity 170L

Power of coolant pump motor 0.75kW

Engines and power supply

Compressed Air Supply 0.6MPa

Voltage 380V / 50Hz / Three phase / AC

Chip and dust removal systems

Chip removal system Chain type chip conveyor

Chip carrier Presence

Other

Lubrication system Full-automatic

Splash guard cover Full splash guard

Overall dimensions and weight

Weight 11000kg

Overall length 4800mm

Overall width 3650mm

Overall height 4000mm
