Xianheng

8-axis CNC spring coiling machine CSM-8250CNC

Серия: CSM

Quantity of controlled axis 8pcs

Wire diameter 8mm — 25mm

Wire feeding speed 70m/min

OD control axis 15kW / 15kW

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Quantity of controlled axis 8pcs

Type of spring Compression

CNC

CNC model Arcuchi

CNC language Chinese / English

Processing parameters

Wire diameter 8mm — 25mm

Wire feeding speed 70m/min

Direction of coiling Right + Left

Controlled axes

OD control axis 15kW / 15kW

Pitch axis 15kW

Wire feed axis 3pcs x 30kW

Cutting axis 30kW / 30kW

Engines and power supply

Voltage 360V / 50Hz / Three phase / AC

Total motor power 195kW

Overall dimensions and weight

Weight 30000kg

Overall length 5860mm

Overall width 2840mm

Overall height 2950mm

Периферия

Wire feeders

ZL-2500
