Machine tools and equipment / Metalworking machine tools / Milling machines / Knee-type milling machines / CNC Horizontal knee-type millling machine XK6040
WEIDA

CNC Horizontal knee-type millling machine XK6040

Серия: XK
Milling machine variation Horizontal milling machine
Working table size 1700mm x 400mm
Spindle speeds range 30rpm — 1500rpm

Цена и условия

4 633 715 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Milling machine variation Horizontal milling machine
Milling Horizontal

Horizontal worktable

Working table size 1700mm x 400mm
T-slots 3pcs / 18mm / 90mm
Max. weight of workpiece 500kg

Horizontal spindle

Spindle speeds range 30rpm — 1500rpm
Spindle taper ISO50
Spindle bore diameter 29mm
Distance from horizontal spindle axist to surface of working table 30mm — 410mm
Distance between spindle axis and ram 450mm
Spindle motor power 11kW

Feeds

Manual feed travels 920mm / 380mm / 350mm
Number of feed speeds No limitation
Min. speed of traverse feeds 6mm/min / 3mm/min / 6mm/min
Max. speed of traverse feeds 3200mm/min / 1600mm/min / 3200mm/min
Rapid traverse 4000mm/min / 2000mm/min / 4000mm/min
Torque of axis-drive motors 15N⋅m / 15N⋅m / 22N⋅m

Indication and control

Indication and control CNC
Model Fanuc 0i MF

Cutting fluid

Power of coolant pump motor 0.125kW

Engines and power supply

Voltage 380V / 50Hz

Overall dimensions and weight

Weight 3850kg
Overall length 2310mm
Overall width 2200mm
Overall height 2394mm

Комплектация

Automatic centralized oil lubrication
Chip collector tray
Collets for milling chuck
Количество: 1 set
Coolant system
Draw bar
Количество: 1 pcs
Mill arbors
Количество: 1 set
Milling chuck
Количество: 1 pcs
ISO50
Oil gun
Количество: 1 pcs
Outer arbor support for horizontal milling
Количество: 1 pcs
Reduction sleeve
Количество: 1 pcs
ISO50/MS4
Tools box
Количество: 1 pcs
Лампа освещения рабочей зоны
