STS

CNC Horizontal Lathe T52

Серия: T

Max. swing diameter over bed 400mm

Max Cutting Diameter 380mm

Processing length 300mm

Chuck size 8″

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Capability

Max. swing diameter over bed 400mm

Max Cutting Diameter 380mm

Processing length 300mm

Headstock

Spindle speeds range 4000rpm

Lathe Spindle Nose A2-6

Spindle bore diameter 62mm

Bar Size 51mm

Spindle torque 70N⋅m

Spindle motor power 11kW / 15kW

Lathe chuck

Chuck size 8″

Clamping type Hydraulic

Feeds

X-Axis travel 220mm

X-axis transmission type 32mm

Z-Axis travel 350mm

Z-axis transmission type 32mm

Rapid traverse 20000mm/min / 20000mm/min

Positioning accuracy 0.01mm / 0.01mm

Repeatability accuracy 0.005mm / 0.005mm

Power of feed motors 1.8kW / 1.8kW

Carriage

Tool post Lathe turret

Number of stations 12pcs

Tool сhanging time (Tool-to-Tool) 0.3sec.

Engines and power supply

Total motor power 20kW

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3000kg

Overall length 1950mm

Overall width 1550mm

Overall height 1800mm
