DN Solutions

CNC turning and milling machining center PUMA 3100SY

Серия: PUMA

Max. swing diameter over bed 850mm

Processing length 765mm

Цена и условия

22 160 628 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

CNC lathe type Combo lathe mill

Y-axis Presence

C axis Presence

Capability

Max. swing diameter over bed 850mm

Max. swing over cross slide: 670mm

Processing length 765mm

Back spindle

Spindle speeds range 4000rpm

Lathe Spindle Nose A2-8

Spindle bore diameter 91mm

C2-axis (sub spindle) resolution 0.001°

Spindle motor power 15kW / 22kW

Feeds

X-Axis travel 293mm

Z-Axis travel 830mm

Y-Axis travel 130mm

Travel distance B 750mm

Rotation range of C-axis 360°

Rapid traverse 30000mm/min / 10000mm/min / 30000mm/min / 200rpm / 30000mm/min

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling

Tools quantity 12pcs

Tool shank diameter 25mm

Motor power 1.5kW / 5.5kW

Live tooling speed 5000rpm

Cutting fluid

Power of coolant pump motor 0.4kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 7000kg

Overall length 3908mm

Overall width 1978mm

Overall height 2315mm
