Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC Turning Centers / CNC turning and milling machining center CUTEX 180AL/YMC
Hwacheon

CNC turning and milling machining center CUTEX 180AL/YMC

Серия: Cutex [A]
Max. swing diameter over bed 700mm
Processing length 478mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / Combo lathe mill
Y-axis Presence
C axis Presence

Capability

Max. swing diameter over bed 700mm
Processing length 478mm

Feeds

X-Axis travel 205mm
X-axis transmission type Ball screw
Z-Axis travel 580mm
Z-axis transmission type Ball screw
Y-Axis travel 55mm
Rapid traverse 36000mm/min / 10000mm/min / 36000mm/min

Feed motor

Power of feed motors 3kW / 1.8kW / 3kW

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling
Tools quantity 12pcs
Tool holder interface BMT55
Tool shank diameter 25mm
Motor power 3.7kW / 5.5kW
Live tooling speed 5000rpm

Tailstock

Tailstock Hydraulic
Morse cone MT4

Cutting fluid

Tank capacity 75L

Hydraulic system

Hydraulic Tank Capacity 11L

Overall dimensions and weight

Weight 3900kg
Overall length 2900mm
Overall width 1700mm
Overall height 1995mm
