MICK

Slant Bed CNC Gang Tool Lathe MDW-6630

Серия: MDW

CNC lathe type Slant-bed CNC lathe / 30°

Max. swing diameter over bed 560mm

Spindle speeds range 4000rpm

Spindle bore diameter 230mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Capability

Max. swing diameter over bed 560mm

Headstock

Spindle speeds range 4000rpm

Spindle bore diameter 230mm

Feeds

X-Axis travel 460mm

Z-Axis travel 630mm

Rapid traverse 30mm/min / 30mm/min

Positioning accuracy 0.0035mm / 0.0035mm

Power of feed motors 1.3kW / 1.3kW

Threading range

Range of metric threads 10mm

Carriage

Number of stations 12pcs

Tool shank 25mm x 25mm

Other

Oil tank capacity 2L

Water tank capacity 100L

Hydraulic Tank Capacity 20L

Engines and power supply

Total motor power 12kW

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3500kg

Overall length 2600mm

Overall width 1780mm

Overall height 1700mm
