Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC Turning Centers / Slant Bed CNC Lathe C400A
JSWAY

Slant Bed CNC Lathe C400A

Серия: C
CNC lathe type Slant-bed CNC lathe / 30°
Max. swing over cross slide: 400mm
Processing length 400mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Capability

Max. swing over cross slide: 400mm
Processing length 400mm

Main spindle

Spindle speeds range 6000rpm
Lathe Spindle Nose A2-5
Bar Size 45mm
Spindle motor power 7.5kW

Feeds

X-Axis travel 840mm
X-axis transmission type Ball screw
Z-Axis travel 300mm
Z-axis transmission type Ball screw
Rapid traverse 30000mm/min / 30000mm/min
Positioning accuracy 0.005mm / 0.008mm
Repeatability accuracy 0.005mm / 0.008mm

Feed motor

Power of feed motors 1.3kW / 1.3kW

Carriage

Tool post Lathe turret

Tools

Tools quantity 10pcs
Motor power 1.3kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3800kg
Overall length 2000mm
Overall width 1750mm
Overall height 1700mm
