JSWAY

Slant Bed CNC Lathe CFG56D

Серия: CFG

CNC lathe type Slant-bed CNC lathe / 45°

Max. swing over cross slide: 350mm

Processing length 100mm

Spindle speeds range 4000rpm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 45°

Capability

Max. swing over cross slide: 350mm

Processing length 100mm

Main spindle

Spindle speeds range 4000rpm

Bar Size 51mm

Spindle motor power 7.5kW

Feeds

X-Axis travel 720mm

X-axis transmission type Ball screw

Z-Axis travel 280mm

Z-axis transmission type Ball screw

Rapid traverse 30000mm/min / 30000mm/min

Positioning accuracy 0.005mm / 0.005mm

Repeatability accuracy 0.005mm / 0.005mm

Tools

Tools quantity 11pcs

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 2900kg

Overall length 2140mm

Overall width 1650mm

Overall height 1930mm
