JSWAY

Slant Bed CNC Lathe CX600

Серия: CX

CNC lathe type Slant-bed CNC lathe / 30°

Max. swing over cross slide: 360mm

Processing length 520mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

Capability

Max. swing over cross slide: 360mm

Processing length 520mm

Main spindle

Lathe Spindle Nose A2-5

Feeds

X-axis transmission type Ball screw

Z-axis transmission type Ball screw

Rapid traverse 30000mm/min / 30000mm/min

Positioning accuracy 0.005mm / 0.005mm

Repeatability accuracy 0.005mm / 0.005mm

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling

Tailstock

Morse cone MT5

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Lubrication system

Lubrication system Full-automatic

Overall dimensions and weight

Weight 4200kg

Overall length 2000mm

Overall width 1750mm

Overall height 1700mm

Периферия

Lathe toolposts

toolpost CX400 BMT45

toolpost CX400
